The wide RPM range from 200 to 2100 RPM can be regulated seamlessly and synchronously with other fans thanks to ARCTIC's PWM Sharing Technology (PST).
The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (min) | 200 RPM |
| Rotational speed (max) | 2100 RPM |
| Noise level (high speed) | 25.5 dB |
| Noise level | 0.45 sone |
| Maximum airflow | 67.56 cfm |
| Airflow | 114.79 m³/h |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Product colour | Black, White |
| Number of fans | 1 fan(s) |
| Number of fan blades | 5 |
| Fan connector | 4-pin + 4-pin |
| Power consumption (typical) | 1.56 W |
| Voltage | 12 V |
| Rated current | 0.13 A |
| Width | 120 mm |
| Depth | 120 mm |
| Height | 27 mm |
| Weight | 140 g |
| Cable length | 0.4 m |
| Package width | 130 mm |
| Package depth | 125 mm |
| Package height | 34 mm |
| Package weight | 175 g |
| Compliance certificates | RoHS |
| Package type | Box |
| Screws included | Yes |
| Number of screws | 4 |
| Mounting hole pattern (W x D) | 105 x 105 mm |
| Country of origin | China |
| Harmonized System (HS) code | 84733080 |
